Weight: |
36,81 kg |
OMNITRONIC MOLLY-12A Subwoofer active black |
Power supply: |
230 V AC, 50 Hz |
Power consumption: |
1000 W |
Protection class: |
Protection class I |
Output power: |
1 x 500 W RMS 2 x 100 W RMS (8 ohms) 2 x 200 W RMS (4 ohms) |
Power connection: |
Mains input via IEC connector (M) mounting version power supply cord with safety plug (provided) |
Frequency range: |
40 - 160 Hz |
Sensitivity: |
103 dB |
Max. SPL: |
128 dB |
DSP: |
Digital signal processor |
DSP presets: |
FLAT; DJ; LIVE; VOICE |
Cooling: |
Temperature-controlled fan |
Control: |
Bluetooth |
Bluetooth device name: |
Omnitronic |
Attachment system: |
Flange: M20 thread |
Circuitry: |
Class D |
Control elements: |
Phase reversal switch, level control per channel, power switch, connect |
Controls: |
Softstart; short-circuit; limiter; Overvoltage; overheat |
Status LED: |
Signal, power, limit, fault, DSP presets |
Connections: |
Input: line via 2 x 3-pin XLR/6.35mm jack (F) combination socket (mounting version) Input: line via 1 x 3.5 mm jack (stereo) mounting version Input: line via 1 x stereo RCA Output: line via 2 x 3-pin XLR Output: Top via 2 x speaker built-in socket (F) |
Input channels: |
1 x stereo via Combination socket or RCA or Bluetooth, channel control via Rotary dial |
Speaker: |
1 x woofer 12" Voice coil lows 3" |
Type of speaker: |
Subwoofer |
Type of construction: |
Vented |
Carrying handle: |
2 pc/pcs |
Material: |
Birch multiplex |
Color: |
Black, textured coating, painted |
Dimensions: |
Width: 47 cm Depth: 57 cm Height: 40 cm |
Weight: |
22,10 kg |
OMNITRONIC MOLLY-6 Top black 2x |
Power: |
Program: 260W Rated: 130W RMS |
Frequency range: |
150 - 20000 Hz |
Sensitivity: |
95 dB (1W/1m) |
Max. SPL: |
119 dB |
Impedance: |
8 ohms |
Attachment system: |
2x Mounting bracket |
Flying points: |
2 x M8 thread |
Connections: |
1 x speaker built-in socket (F) 1 x screw plug-in terminal |
Speaker: |
1 x woofer 6,5" Basket material: Steel Voice coil lows 1" 1 x Tweeter 1" |
Type of speaker: |
On-ceiling/on-wall speaker; Coaxial speaker |
Material: |
MDF (Medium-density fiberboard) |
Color: |
Black, textured coating, painted |
Dimensions: |
Width: 18,3 cm Depth: 21,4 cm Height: 23 cm |
Weight: |
8,90 kg |
OMNITRONIC BOB-4 Stand Adaptor black 2x |
Maximum carrying capacity: |
30 kg |
Type (general stands): |
Accessory |
Material: |
Steel (powder-coated) |
Color: |
Black |
Weight: |
380 g |
OMNITRONIC Speaker Stand BOB System |
Maximum carrying capacity: |
14 kg |
Height: |
Maximum: 195 cm Minimum: 107 cm Adjustable in 6 steps with locking pin |
Attachment system: |
M10 thread |
Type (general stands): |
Speaker stand/manual |
Material: |
Steel |
Color: |
Black, painted; , scratchproof and shockproof |
Main pipe diameter: |
Ø 3 cm |
Extension tube diameter: |
Ø 2,5 cm |
Weight: |
2,15 kg |
OMNITRONIC BOB Transport Bag for Tripod/Distance Tube |
Material: |
Textile |
Color: |
Black |
Dimensions: |
Width: 1,06 m Depth: 9 cm Height: 7 cm |
Weight: |
190 g |
OMNITRONIC Speaker cable Speaker 2x1.5 5m bk |
Cable construction: |
2 x 1,5 mm² speaker cable |
Cable length: |
5 m |
Plug A: |
1 x 2-pin speaker (M) |
Plug B: |
1 x 2-pin speaker (M) |
Color: |
Black |
Weight: |
370 g |
