Weight: |
18,11 kg |
EUROLITE LED 7C-7 Silent Slim Spot |
Power supply: |
100-240 V AC, 50/60 Hz |
Power consumption: |
45 W |
IP classification: |
IP20 |
Power connection: |
Mains input via P-Con (blue), mounting version power supply cord with safety plug (provided) |
Power output: |
1 x P-Con (gray), mounting version |
Fuse: |
5 x 20 mm, T 1 A Fuse replaceable |
Lamp type: |
LED lamp |
LED: |
7 x 9 W high-power 7in1 SCL RGB/CW/WW/A/UV (homogenous color mix) |
Flash rate: |
0 - 20 Hz |
DMX channels: |
3; 4-1; 4-2; 4-3; 4-4; 5; 6; 7; 9; 12 |
DMX input: |
1 x 3-pin XLR (M) mounting version |
DMX output: |
1 x 3-pin XLR (F) mounting version |
Cooling: |
Passive convection cooling |
Control: |
Stand-alone; DMX; IR remote control; Sound to light via Microphone; Master/slave function; QuickDMX via USB (optional); W-DMX by wireless solution via USB (optional); CRMX by LumenRadio via USB (optional) |
Preprogrammed in: |
LED PC-Control 512; EASY SHOW 1; Light Captain; EASY SHOW 2; EASY SHOW 3 |
Projection: |
Flicker-free |
Beam angle: |
15° |
Beam angle (1/2 peak): |
15° |
Beam angle (1/10 peak): |
33° |
Color rendering index (CRI): |
92 Ra |
Housing color: |
Black |
Attachment system: |
Double bracket |
Display type: |
4 digit 7-segment LED display |
USB port: |
Typ A |
Material: |
Aluminum casting; metal |
Dimensions: |
Width: 22 cm Depth: 11 cm Height: 25,5 cm |
Weight: |
2,60 kg |
Noise classification: |
Class 0 (no noise at all) |
Photobiological safety: |
Risk Group 0 |
Power cord |
Cable construction: |
3 x 1,0 mm² H05VV-F |
Cable length: |
Approx. 1,2 m |
Mounting bracket |
Diameter mounting holes: |
1 x Ø11mm |
Material: |
Metal, 2,5 mm |
Remote control |
Battery: |
1 x Button cell 3.0 V CR2025 lithium manganese built-in |
Legal specifications |
Special product: |
Not designed for household room illumination |
Intended use: |
Show effect lighting |
EUROLITE QuickDMX USB Wireless Transmitter/Receiver |
Power supply: |
5 V DC |
IP classification: |
IP20 |
Power connection: |
Mains input via USB A (M) connectable version |
DMX channels: |
Input 512 Output 512 |
DMX output: |
1 x USB, type A |
Control: |
DMX; QuickDMX; plug and play |
Range: |
Range up to 400m with line-of-sight |
Carrier frequency: |
2,4 GHz |
Parallel mode: |
Max. 6 transmitter |
Modulation: |
GFSK |
Color: |
Black |
Dimensions: |
Width: 8,6 cm Depth: 4 cm Height: 1,1 cm |
Weight: |
10 g |
ROADINGER Flightcase 4x SLS Size M |
Maximum load: |
25 kg |
Aluminum profile frames: |
30 mm |
Case handle: |
1 pc/pcs |
Stop hinge: |
2 pc/pcs |
Lock: |
Butterfly lock: 1 pc/pcs |
Use of brands: |
Branded hardware |
Material: |
Birch multiplex, 7 mm |
Color: |
Dark brown, laminated |
Compartment dimensions: |
12 cm x 25 cm x 35,5 cm |
Inside dimensions: |
49,5 cm x 25 cm x 35,5 cm |
Dimensions: |
Width: 52,5 cm Depth: 28,5 cm Height: 44,5 cm |
Weight: |
7,65 kg |
