Art-Net interface for control of 50000 digital LED channels
- Can receive and process up to 2048 DMX channels
- 1 to 6 colors per pixel
- Supports pixel groups (1 - 9999)
- Control via Art-Net; sACN
- Configuration with website or Art-Net
- Useable for WS2801; WS2811, WS2812, SK6812; APA102 LED´s
- Does not require a separate adapter - power supply is via LED strip (5-12 V)
- Rugged metal housing
- Desktop console housing
- Made in Germany
- The device can be connected via RJ-45 etherCON (F) mounting version to the PC in connection with f.e. FreeStyler, DMXControl 3, PC_DIMMER, Lightkey (MAC)
- Built with NEUTRIK connector
| Power supply: |
5-12V DC |
| Pin configuration: |
Pin1 (GND) / Pin2 (DATA) / Pin3 (CLOCK) / Pin4 (VIN) |
| Power consumption: |
1 W |
| IP classification: |
IP20 |
| Power connection: |
Mains input via 4-pin screw plug connector (M) mounting version |
| DMX channels: |
Input 2048 |
| Network connection: |
Protocol: Ethernet TCP/IP via 1x RJ-45 etherCON (F) mounting version, 10 Mbit/s
Standard: IEEE 802.3u |
| Control: |
Art-Net; sACN |
| Control channels: |
50000 |
| Housing color: |
Black |
| Status LED: |
Signal, link |
| Connections: |
Input: 1 x RJ-45 etherCON (F) mounting version
Output: screw plug-in terminal |
| Use of brands: |
Built with NEUTRIK connector |
| PC connect: |
F.e. FreeStyler, DMXControl 3, PC_DIMMER, Lightkey (MAC) via RJ-45 etherCON (F) mounting version |
| Housing design: |
Desktop console housing |
| Dimensions: |
Length: 7,8 cm
Width: 5,0 cm
Height: 4,2 cm |
| Weight: |
0,25 kg |
| Item information |
Value |
| Shipping weight: |
0,40 kg
|
| Item weight: |
0,30 kg
|
| Dimensions
( Length × Width × Height ):
|
45,00 × 175,00 × 115,00 cm |
